Puzzolana PW3T Base

Specifications of Puzzolana PW3T Base

Engine

• Axle Base 1800mm
• Emission Norms BS-lll
• Engine H.P 125 HP@2100 RPM Cummins
• Gradeability 30%
• Load capacity 3 Tons
• Max. Torque 659 N.m @1600RPM
• Overall Length with Std. Bucket 7053mm.
• Speed Max 35 km/h
• Std. Bucket Capacity 1.7m3
• Transmission (Hyd. Power Shift) 4 forward,2 reverse
• Wheel Base 2607mm.

Transmission

• Transmission 4WD planetary hydraulic power shift with pilot operated shifting.

Operating Weights

• Operating weight 10.3 tons

Axles

• Final drives Spur gear planetary single stage reduction.
• Main drive type Spiral bevel gear with single stage reduction.

Brakes

• Parking Brake Spring applied band brake at transmission drive line input.
• Service brakes All wheel disc brakes, air assist with booster,

Cab

• Cabin A/C cab with best visibility in this class of loader with sculpted bubble shaped wind shield.

Electrical

• ELECTRICALS DC : 24V system

Hydraulics

• Operation Pilot operated dual mode joystick
• Pump Gear pump

STEERING SYSTEM

• STEERING SYSTEM Articulated steering system with a separate steering pump for low effort sensitive steering.
