Schwing Stetter XCT50_Y Truck Crane
Ex-showroom Price
Price not available
Variants
Schwing Stetter XCT50_Y Truck Crane Truck Description
The Schwing Stetter XCT50 Y Truck Crane is a powerful 50-ton lifting solution that perfectly balances durability and performance. Its long boom and high lifting torque make it suitable for large industrial sites. On MotorBazee, you can find details of its safety features and intelligent control system. This crane delivers reliable performance even in challenging projects. Its ergonomic design supports long operating hours.
Key Specifications of Schwing Stetter XCT50_Y Truck Crane Equipment
Calculate Schwing Stetter XCT50_Y Truck Crane Monthly EMI
20
Monthly EMI
Down Payment
₹ 0
Total Loan Amount
₹ 0
Specifications of Schwing Stetter XCT50_Y Truck Crane
Engine
- Engine Model WP9H336E62
- Max. net power/rotationspeed 242/1900 kW/(r/min)
- Max. output torque/rotationspeed 1600/1000-1400 N.m/(r/min)
- Max. output torque/rpm 1600/1000-1400N.m/(r/min)
- Rated power/ rotationspeed 247/1900kW/(r/min)
Dimensions
- Dimensions (length×width×height) 14045 2790 3615 mm
- Front/ Rear extension 2145/0 mm
- Front/ Rear overhang 2376/2404 mm
- Track（Front/ Rear ） 2304/2081 mm
WEIGHT
- Axle load 8500 kg/8500 kg/ 11550kg/11550kg
- Total vehicle mass in travel configuration 40100kg
Noise Emissions
- Noise level at seated position ≤90 dB(A)
Performance Data
- Boom length Base boom 11.2 m
- Boom length Fully-extended boom + Jib 60.5 m
- Hoist height Fully-extended boom 44.1m
- Hoist height Fully-extended boom + Jib 60 m
- Jib offset angle 0, 15, 30
- Max. load moment Base boom 2050kN.m
- Max. load moment Fully-extended boom + Jib 725 kN.m
- Max. load moment Fully-extended boom 1040kN.m
- Max. total rated lifting capacity 50 t
- Min. rated working radius 3 m
- Outrigger span Lateral 7.1 m
- Outrigger span Longitudinal 6.1m
- Turning radius at turntable tail 3800mm
Travel section
- Approach angle 19
- Braking distance (at 30 km/h ) ≤10 m
- Departure angle 13
- Exterior noise level ≤84 dB(A)
- Fuel consumption per 100 km 38L
- Max. grade ability ≥40%
- Max. travel speed ≥48 km/h
- Min. ground clearance 260 mm
- Min. stable travel speed 2 ~3 km/h
- Min. turning diameter ≤24 m
- Min. turning diameter at boom head ≤30.2 m
Working speed
- Boom fully extending time ≤100
- Boom raising time ≤50
- Hoisting speed (single line, 4th layer,no load) Auxiliary winch ≥128 m/min
- Hoisting speed (single line, 4th layer,no load) Main winch ≥128 m/min
- Max. slewing speed ≥2 r/min
- Outrigger extending and retracting time Outrigger beam Extending ≤40 s
- Outrigger extending and retracting time Outrigger beam Retracting ≤35 s
- Outrigger extending and retracting time Outriggerjack Extending ≤40 s
- Outrigger extending and retracting time Outriggerjack Retracting ≤35 s
